FLAT CABLES
300/500V
Code
:Flat Cables
Standard:TS9760,IEC227,VDE 0281,BS6500
Construcion:1-Flexible Copper Conductor
2-PVC insulation
3- PVC outer sheath
Application:Preferably for installation indoors, in cable ducts and in industrial plants or switching stations,
underground installation,with adlditional protection where mechanical damage is unexpected.
Technical Data:Max.operating temperature 70℃
Short ciruit temperature 160℃
Num. of Cores and Nominal Cross Section | Wire diameter | Thickness of insulation | Thickness of Sheath | Conductor DC resistance at 20℃ | Approx. Total Weight | Max. Curent Carying Capacity at 30℃ | |
No×mm² | mm | mm | mm | Q/km | Kg/km | Pipe A | Air A |
2 × 1 | 1.1 | 0.6 | 0.8 | 18.1 | 50.0 | 一 | 19 |
2 × 1.5 | 1.35 | 0.7 | 0.8 | 12.1 | 66.0 | 32 | 20 |
2× 2.5 | 1.73 | 0.8 | 1.0 | 7.41 | 104 | 42 | 20 |
2 × 4 | 2.19 | 0.8 | 1.1 | 4.61 | 143 | 54 | 20 |
3 × 1 | 1.1 | 0.6 | 0.8 | 18.1 | 73.0 | 一 | 20 |
3 ×1.5 | 1.35 | 0.7 | 0.9 | 12.1 | 101 | 26 | 20 |
3 × 2.5 | 1.73 | 0.8 | 1.1 | 7.41 | 158 | 34 | 20 |
3 × 4 | 2.19 | 0.8 | 1.2 | 4.61 | 216 | 44 | 20 |
FLAT CABLES
300/500V
Code:Flat Cables
Standard:TS9760,IEC227,VDE 0281,BS6500
Construcion:1-Flexible Copper Conductor
2-PVC insulation
3- PVC outer sheath
Application:Preferably for installation indoors, in cable ducts and in industrial plants or switching stations,
underground installation,with adlditional protection where mechanical damage is unexpected.
Technical Data:Max.operating temperature 70℃
Short ciruit temperature 160℃
Num. of Cores and Nominal Cross Section | Wire diameter | Thickness of insulation | Thickness of Sheath | Conductor DC resistance at 20℃ | Approx. Total Weight | Max. Curent Carying Capacity at 30℃ | |
No×mm² | mm | mm | mm | Q/km | Kg/km | Pipe A | Air A |
2 × 1 | 1.1 | 0.6 | 0.8 | 18.1 | 50.0 | 一 | 19 |
2 × 1.5 | 1.35 | 0.7 | 0.8 | 12.1 | 66.0 | 32 | 20 |
2× 2.5 | 1.73 | 0.8 | 1.0 | 7.41 | 104 | 42 | 20 |
2 × 4 | 2.19 | 0.8 | 1.1 | 4.61 | 143 | 54 | 20 |
3 × 1 | 1.1 | 0.6 | 0.8 | 18.1 | 73.0 | 一 | 20 |
3 ×1.5 | 1.35 | 0.7 | 0.9 | 12.1 | 101 | 26 | 20 |
3 × 2.5 | 1.73 | 0.8 | 1.1 | 7.41 | 158 | 34 | 20 |
3 × 4 | 2.19 | 0.8 | 1.2 | 4.61 | 216 | 44 | 20 |
