This cable clamp is a sort of module assembly for fixing cables. It' s made of resist ultraviolet and enduring high temperature material. It fits for fixing the circular fiber cable of φ7mm orφ7.5mm and 3.3 square, 4 square, 6 square, 8.3 square cable. It can set three fiber cables and three cables in most. The C-shape bracket is light and terse and It' s easy to fix reliably.
1. Disentwine the special bolt of the C-bracket till the ringent distance is bigger than the thick of one
side of angle iron. And then tighten the special bolt M8; (Reference torque: 15Nm)
2. Please retire the nut onto the threaded rod ,and unclench the plastic clip;
3. Disjoin the plastic clamp,plunge the Fiber cable ofφ7mm orφ7.5mm into the small hole of plastic
clamp, plunge the 3.3 square or 4 square cable into the hole of the black rubber pipe in plastic clamp.
Remove the rubber pipe from the plastic clamp for the 6 square or 8.3 square cable and plunge the
cable into the hole of plastic clamp (figure right);
4. Lock all nuts at last. (Reference torque of lock nut M8 for clamp: 11Nm)
