BV H07V-U Copper Conductor PVC Insulated Wire Compliant with BS6004 and VDE0281-3 Standards

5 0 Reviews
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

H07V-U

450/750V







Code: :BV,HO7V-U,NYA

Standard:227IECO1,BS6004,VDEO281-3

Construcion:1-Solid  Copper  Conductor

                     :2-PVC insulation


Application :Preferably for installation indoors, in cable ducts and in industrial plants or switching stations,

underground installation.

Technical Data:Max.operaing  temperature  70℃

Short circuit temperature 160℃






Nominal

Cross

Section

Wires

diameter

Thickness of insulation

Mean overall diameter

Conductor DC

resistance at 20℃

Approx.

Total

Weight

Max.Current

Carrying

Capacity at 30℃

mm²

mm

mm

min

max

42/km

Kg/km

Pipe A

Air A

1.5

1.35

0.7

2.6

3.2

12.1

19

16

24

2.5

1.73

0.8

3.2

3.9

7.41

29

20

32

4

2.19

0.8

3.6

4.4

4.61

42

26

42

6

2.68

0.8

4.1

5.0

3.08

62

35

55

10

3.50

1.0

5.3

6.4

1.83

110

46

75
